| 基本尺寸 | 基本额定载荷 | 轴承类型 | 轴承图片 | 型号 | |||
|---|---|---|---|---|---|---|---|
| dynamic | static | Type | Images | Model | |||
| d[mm] | D[mm] | B[mm] | C[kN] | C0[kN] | |||
| 1016 | 1270 | 2750 | 7500 | 圆锥滚子轴承 |  |
EE 168400/168500 | |
| 977.9 | 1130.3 | 1450 | 4400 | 圆锥滚子轴承 | |
LL 687949/910 | |
| 900 | 1180 | 3960 | 9150 | 圆锥滚子轴承 | |
BT1B 328214/HA5 | |
| 857.25 | 1092.2 | 2810 | 7350 | 圆锥滚子轴承 | |
EE 157337/157430 | |
| 838.2 | 1041.4 | 1900 | 4800 | 圆锥滚子轴承 | |
EE 763330/763410 | |
| 801.688 | 914.4 | 1100 | 3550 | 圆锥滚子轴承 | |
LL 584449/410 | |
| 774.7 | 965.2 | 1940 | 4900 | 圆锥滚子轴承 | |
EE 752305/752380 | |
| 762 | 889 | 1230 | 3800 | 圆锥滚子轴承 | |
LL 483449/418 | |
| 762 | 889 | 1870 | 5850 | 圆锥滚子轴承 | |
L 183449/410 | |
| 760 | 889 | 1870 | 5850 | 圆锥滚子轴承 | |
L 183448/410 | |
| 760 | 889 | 1230 | 3800 | 圆锥滚子轴承 | |
LL 483448/418 | |
| 749.3 | 990.6 | 4570 | 12000 | 圆锥滚子轴承 | |
LM 283649/610/HA1 | |
| 723.9 | 914.4 | 2050 | 4900 | 圆锥滚子轴承 | |
EE 755285/755360 | |
| 711.2 | 939.8 | 2640 | 6200 | 圆锥滚子轴承 | |
BT1B 328068/HA4 | |
| 710 | 950 | 2860 | 6550 | 圆锥滚子轴承 | |
BT1B 332890/HA1 | |
| 710 | 950 | 2860 | 6550 | 圆锥滚子轴承 | |
BT1B 332890 | |
| 685.8 | 876.3 | 2120 | 5500 | 圆锥滚子轴承 | |
EE 655270/655345 | |
| 682.625 | 965.2 | 5120 | 12500 | 圆锥滚子轴承 | |
332283 | |
| 682.625 | 1080 | 6710 | 13200 | 圆锥滚子轴承 | |
BT1B 332705/HA4 | |
| 680 | 1000 | 5610 | 12700 | 圆锥滚子轴承 | |
BT1B 332787/HA4 | |
| 679.45 | 901.7 | 3580 | 9000 | 圆锥滚子轴承 | |
LM 281849/810/HA4 | |
| 660.4 | 812.8 | 1940 | 5600 | 圆锥滚子轴承 | |
L 281147/110 | |
| 660.4 | 1000 | 4400 | 9500 | 圆锥滚子轴承 | |
BT1B 334140/HA4 | |
| 660.4 | 939.8 | 3740 | 8150 | 圆锥滚子轴承 | |
332383 | |
| 635 | 736.6 | 858 | 2650 | 圆锥滚子轴承 | |
80780/80720 | |
| 609.6 | 787.4 | 2160 | 5300 | 圆锥滚子轴承 | |
EE 649240/649310 | |
| 607.72 | 787.4 | 2160 | 5300 | 圆锥滚子轴承 | |
EE 649239/649310 | |
| 560 | 1080 | 8970 | 16000 | 圆锥滚子轴承 | |
BT1B 334018/HA5 | |
| 558.8 | 736.6 | 2330 | 5700 | 圆锥滚子轴承 | |
LM 377449/410 | |
| 558.8 | 736.6 | 1830 | 4150 | 圆锥滚子轴承 | |
EE 843220/843290 | |
